MultiZero Vise Single Wedge

The MultiZero Vise Single Wedge is a key element of the MultiZero Modular Vise System, designed for efficient and secure workpiece clamping. Mounted on the MultiZero Rail, this single wedge clamp offers precise positioning adjustment with a 2.5 mm pitch, ensuring accurate alignment during machining. Featuring replaceable jaws with a positive downforce design, it provides durability and protection from dirt, ensuring reliable performance and extended lifespan. This versatile clamp streamlines modular clamping for a wide range of workpieces, enhancing productivity within the MultiZero Clamping System.

MultiZero Vise Single Wedge

MultiZero Vise Single Wedge provides precise 2.5 mm adjustment and durable, dirt-resistant jaws for secure, reliable clamping.

Product Product no. Jaw height (h) Clamping force (kN) Width (w) Weight (kg)
MultiZero Vise Single Wedge W50 H23
2B4-1110-1
23.0 mm
15 kN
50.0 mm
0.72 kg
Product Product no. Jaw height (h) Clamping force (kN) Width (w) Weight (kg)
MultiZero Vise Single Wedge W50 H35
2B4-1150-1
35.0 mm
30 kN
50.0 mm
1.05 kg
