MultiZero Riser W80
The MultiZero Riser W80 offers five-sided machining with no limitations on workpiece size or shape. It provides precise, repeatable clamping, making it suitable for large workpieces and general 5-axis machining. With a range of height extensions and adapters, the system is flexible and efficient for various setups.
MultiZero Riser W80
Workpiece clamping fixture that enables five-sided machining. Perfect for general 5-axis machining or clamping of large workpieces.
| Product | Product no. | Height (h) | Clamping force (kN) | Ø (A) | Ø (B) | Weight (kg) |
|---|---|---|---|---|---|---|
|
MultiZero Riser W80 H80 |
3B6-1010-0 |
80.0 mm |
25 kN |
75.0 mm |
90.0 mm |
4.08 kg |
| Product | Product no. | Height (h) | Clamping force (kN) | Ø (A) | Ø (B) | Weight (kg) |
|---|---|---|---|---|---|---|
|
MultiZero Riser W80 H160 |
3B6-1320-0 |
160.0 mm |
25 kN |
75.0 mm |
90.0 mm |
7.58 kg |
| Product | Product no. | Height (h) | Clamping force (kN) | Ø (A) | Ø (B) | Weight (kg) |
|---|---|---|---|---|---|---|
|
MultiZero Riser W80 H240 |
3B6-1330-0 |
240.0 mm |
25 kN |
75.0 mm |
90.0 mm |
11.15 kg |
